10L Small Emulsifier Mixer Machine Lab Homogenizer Laboratory Homogeneous Emulsifier

ERIC-10L glass Laboratory homogeneous emulsifier

I. equipment introduction

10L Small Emulsifier Mixer Machine Lab Homogenizer Laboratory Homogeneous Emulsifier
10L Small Emulsifier Mixer Machine Lab Homogenizer Laboratory Homogeneous Emulsifier
10L Small Emulsifier Mixer Machine Lab Homogenizer Laboratory Homogeneous Emulsifier


Vacuum emulsifier is mainly composed of emulsifier, vacuum system, lifting system, electrical control system, etc.

The equipment is mainly used in daily chemical care products, biomedicine, food industry, coating ink, nano materials, petrochemical industry, printing and dyeing auxiliaries, paper industry, pesticide and chemical fertilizer, plastic rubber, power electronics, other fine chemicals, etc., especially for material emulsification configuration with high matrix viscosity and solid content.


II. Equipment features

★ the company produces various types of vacuum emulsification, in which the homogenization system is divided into upper homogenization, lower homogenization, internal and external circulation, and the mixing system is divided into single-phase mixing, two-way mixing and spiral mixing; and it can customize various qualified and high-quality products according to customer requirements;

★ frequency converter is used for speed regulation of mixing, which can meet the production requirements of different processes;

★ homogeneous structure of German technology, with imported double face mechanical seal effect

★ vacuum defoaming makes the materials meet the aseptic requirements, and vacuum suction is used, especially for powder materials to avoid dust flying;

★ the lifting device can be selected for the main pot cover, which is convenient for cleaning and has more significant cleaning effect. The pot body can be selected for dumping;

★ the pot body is composed of three layers of stainless steel imported plate welding, and the tank body and pipeline are mirror polished, fully in line with GMP requirements;

★ according to the process requirements, the tank body can heat and cool the materials, and the heating methods mainly include steam and electric heating;

★ in order to ensure the requirements of the whole customer, the electrical appliances can be imported configuration, which can completely meet the international standards.


Main technique parameters
The main pot
Serial numberProduct nameTo configure Remarks
1Mixing method1.A one-way paddle with a scraping wall,power 0.37KW,speed 0-180r/minFrequency control  ,Scraped wall material polytetrafluoroethylene or silica gel
2,Homogenizer power 0.55KW,Speed 10000-28000r/minGermany Milwaukee
2Sealing processmachine seal
3Boil the wayElectric lifting 0.05KW
4Feeding modeManual dumping ,Bottom manual discharge
5Temperature displayResistance thermometer(140ºC)
6Heating and cooling nodeSteam heating, water cooling
7Pressure vacuum displayVacuum meter(gauge) max -0.07Mpa
7Main process parameters1.Working pressure of jacket 0.1Mpa
2.Maximum working volume 12L
3.Effective working volume 10L
4Minimum working volume 5L
8Texture of materialHigh borosilicate glass kettleThrough MA detection
9Area covered800mm*510mm
10high1000mmHeight of the main pot cover
1350mmRaising height of main pot cover
11Voltage 220v/ 60hz
12Weight 55kgs


Matching combination
Serial numberProduct nameTo configureRemarks
1BracketAll stainless steel support
2Emulsification cookerMaterial filter,spice bucket,air filter etc
3Material pipe316l stainless steel pipe is used in contact with material
4Electric control system The main pot is integrated, and the manual button fully controls the main potUse the manual button


Power consumption
Serial numberProduct nameTo configureRemarks
15L Emulsification pot1. Frame blade mixing 0.37KW
2.homogenizer 0.55KW,homogeneity
3Lifting power 0.05KW
2vacuum pump0.125KW
                                              GERMANY HOMOGENIZER MOTOR      TENGYUAN VACUUM PUMP  ELECTRIC MOTOR





Matching combination
Serial numberProduct nameTo configureRemarks
1BracketAll stainless steel support
2Emulsification cookerMaterial filter,spice bucket,air filter etc
3Material pipe316l stainless steel pipe is used in contact with material
4Electric control system The main pot is integrated, and the manual button fully controls the main potUse the manual button


Power consumption
Serial numberProduct nameTo configureRemarks
15L Emulsification pot1. Frame blade mixing 0.25KW
2.homogenizer 1.2 KW,homogeneity
3Lifting power 0.05KW
2vacuum pump0.125KW
                                      HOMOGENIZER MOTOR      TENGYUAN VACUUM PUMP      ELECTRIC MOTOR
